Solving Intel NIC hangups on Proxmox VE 8.4-1
Recently I've been seeing my NAS' network interface go down unrecoverably (i.e. until a reboot). The first time I've observed this, I happened to be running some OS upgrades, so I brushed it off as a one-time, wonky interaction with the network interface. However, I've noticed that it kept happening from time to time, so I started wondering about a common denominator of all of these events. It would only happen during high network throughput tasks, which saturated the gigabit link in a sustained fashion, like dumping backups or pulling several GBs of packages. On the other hand, the issue would never reproduce during light loads (network-wise), like tweaking configs over SSH (even during long-lived sessions).
The environment
The suspected NAS host is a NixOS VM running on top of Proxmox VE, which implies there's some virtual network complexity at play. To briefly explain the infrastructure, the VMs are networked to the hypervisor's physical interface via a linux bridge interface. Logically, it's like a layer 2 switch, allowing to connect multiple virtual NICs, via physical hypervisor interfaces, to the underlying lab network.
Side note about virtualization
These NIC hangups quickly sent me down memory lane. Circa 2021, I was working on building out virtualization infrastructure for testing an embedded Linux device's software in its early stages. The crux of it was that it had several, multi-gigabit NICs, alongside some other physical interfaces, highly sensitive to timing. If I recall correctly, we did eventually have an early hardware prototype in the lab, but it wasn't fit for integrating into a CI pipeline, let alone doing so at scale. The challenge with virtualization here, was that the guest OS was a custom-built Yocto image, designed for the real thing.
Generally speaking, virtualizing a hardware-oriented device always calls for some trade-offs. One cannot simply run nor test everything in a VM, since there's a boundary, beyond which you can't play pretend anymore (performance or inability to virtualize), or the pretending just stops being reasonably cost-effective (cheaper to use hardware, than build out custom tools enabling further virtualization). For example:
- Mocking DMI table info? Easy.
- Setting up disks for a software RAID? Easy.
- Passing through some USB devices? Easy.
- Getting the virtual NICs to behave exactly the same way as your SFP modules of choice, in a way that's compatible with the purpose-built software? What color do you want your dragon?.
Software-side accommodations eventually need to be considered, e.g. flags that inform the kernel it needs to boot with a slightly different configuration. Likewise, services might need to be mocked, or disabled altogether, due to the inability to satisfy certain hardware requirements. This implies there are some limitations to virtualized testing environments, but it's often still far better than nothing, when hardware units are scarce.
Now, back on topic!
Finding the root cause
I happen to have another NixOS machine with an Intel NIC in my lab. It runs bare-metal with the same network configuration, without any hiccups whatsoever, so naturally I suspected the virtual NIC to be the culprit. However, this specific situation was different. Not only the VM, but the PVE hypervisor too, were becoming unreachable — simultaneously, like clockwork. Any attempt to reach the PVE hypervisor, let alone log into the console, resulted in connection failures. This behavior indicated it wasn't the VM's NIC, but rather the hypervisor's NIC that was failing, causing the VM to go dark as a symptom of the broader issue.
By this point, I could reproduce the failure reliably, by saturating the NAS interface with iperf, with the other end of the link running on my router. In retrospect, saturating the hypervisor's interface might've been enough, but at the time I wanted to synthetically simulate the naturally occuring traffic flow through the NAS. Once the hypervisor's interface was trashed, I gracefully power cycled the machine, and started looking at kernel logs from the previous boot:
journalctl --dmesg --boot -1
Looking towards the end, I found a flurry of repeating errors, relating to the e1000e kernel module:
May 25 15:23:30 pve-02 kernel: e1000e 0000:00:19.0 eno1: Detected Hardware Unit Hang:
TDH <61>
TDT <90>
next_to_use <90>
next_to_clean <60>
buffer_info[next_to_clean]:
time_stamp <1000936a9>
next_to_watch <61>
jiffies <1000ca540>
next_to_watch.status <0>
MAC Status <80083>
PHY Status <796d>
PHY 1000BASE-T Status <3800>
PHY Extended Status <3000>
PCI Status <10>
######## SNIP ########
May 25 15:23:32 pve-02 systemd-shutdown[1]: Syncing filesystems and block devices.
May 25 15:23:32 pve-02 systemd-shutdown[1]: Sending SIGTERM to remaining processes...
May 25 15:23:32 pve-02 systemd-journald[339]: Received SIGTERM from PID 1 (systemd-shutdow).
Searching the web for that error shows it's likely caused by a fault in TCP checksum offloading.
NIC driver/configuration comparison
Before proceeding, let's compare the NICs and the corresponding configurations across my Linux servers, just to make sure.
Here's how I grabbed the necessary information from a single host:
# Dump NIC kernel driver and firmware info
root@pve-02:~# ethtool -i eno1
driver: e1000e
version: 6.8.12-10-pve
firmware-version: 0.13-4
expansion-rom-version:
bus-info: 0000:00:19.0
supports-statistics: yes
supports-test: yes
supports-eeprom-access: yes
supports-register-dump: yes
supports-priv-flags: yes
# Dump PCI devices' info. Requires the controller entry to be found manually.
root@pve-02:~# lspci -nn -v
######## SNIP ########
00:19.0 Ethernet controller [0200]: Intel Corporation Ethernet Connection I217-LM [8086:153a] (rev 04)
DeviceName: Onboard LAN
Subsystem: Dell Ethernet Connection I217-LM [1028:05a4]
Flags: bus master, fast devsel, latency 0, IRQ 28, IOMMU group 5
Memory at f7c00000 (32-bit, non-prefetchable) [size=128K]
Memory at f7c3d000 (32-bit, non-prefetchable) [size=4K]
I/O ports at f080 [size=32]
Capabilities: [c8] Power Management version 2
Capabilities: [d0] MSI: Enable+ Count=1/1 Maskable- 64bit+
Capabilities: [e0] PCI Advanced Features
Kernel driver in use: e1000e
Kernel modules: e1000e
######## SNIP ########
| Host | Model | e1000e driver version | Working properly? |
|---|---|---|---|
m920q | I219-LM (rev 10) | 6.12.30 | ✅ |
pve-03 | I219-V | 6.8.12-10-pve | ✅ |
pve-02 | I217-LM (rev 04) | 6.8.12-10-pve | ❌ |
The driver version is essentially the OS kernel version, visibly running PVE kernels on the PVE hosts.
I've also retrieved the offload feature enablement status across the same hosts, using:
ethtool --show-features <iface_name> | grep offload
| feature \ host | m920q | pve-03 | pve-02 |
|---|---|---|---|
tcp-segmentation-offload | on | off | on |
generic-segmentation-offload | on | on | on |
generic-receive-offload | on | on | on |
large-receive-offload | off [fixed] | off [fixed] | off [fixed] |
rx-vlan-offload | on | on | on |
tx-vlan-offload | on | on | on |
l2-fwd-offload | off [fixed] | off [fixed] | off [fixed] |
hw-tc-offload | off [fixed] | off [fixed] | off [fixed] |
esp-hw-offload | off [fixed] | off [fixed] | off [fixed] |
esp-tx-csum-hw-offload | off [fixed] | off [fixed] | off [fixed] |
rx-udp_tunnel-port-offload | off [fixed] | off [fixed] | off [fixed] |
tls-hw-tx-offload | off [fixed] | off [fixed] | off [fixed] |
tls-hw-rx-offload | off [fixed] | off [fixed] | off [fixed] |
macsec-hw-offload | off [fixed] | off [fixed] | off [fixed] |
hsr-tag-ins-offload | off [fixed] | off [fixed] | off [fixed] |
hsr-tag-rm-offload | off [fixed] | off [fixed] | off [fixed] |
hsr-fwd-offload | off [fixed] | off [fixed] | off [fixed] |
hsr-dup-offload | off [fixed] | off [fixed] | off [fixed] |
Given that pve-02 and pve-03 run the same e1000e driver version, I'm now suspecting it's the tcp-segmentation-offload feature that's causing the NIC to fail — that's the only difference in the offload feature configuration between the two hosts. But still, those are two different controllers, so more (different) tweaking might be necessary.
The solution
Here are some potential workarounds I found in relation to my observations:
- disable the C1E power state via BIOS;
- disable NIC TCP checksum offloading;
- flashing the NIC with a patched firmware update;
- replace the hardware NIC.
All in all, I'd prefer not to disable features beneficial to performance and/or the system's efficency. Disabling TCP checksum offloading would lead to increased CPU overhead. Disabling C1E might impact core wake up times, leading to worse general performance. I'm also not keen on getting a new physical NIC, since it costs money and increases power consumption (+1 PCIe module to power).
Finally, Intel doesn't seem to have released any firmware patches for this specific NIC before EOL, so I've opted to disable the offending offloading feature(s).
Let's do this piecemeal and start by disabling tso first, just like it's configured on pve-03.
ethtool --features eno1 tso off
I've initiated an iperf3 server on my router, and started the client on the PVE host. I've opted for a fairly aggressive configuration for this test, with 100 parallel connections and 100G of total payload.
iperf3 -c 192.168.1.1 -p 4625 -P 100 -n 100G
The full payload has been transmitted without any hangups, and the SSH session was still interactive right after completion — no issues whatsoever. Given that the new configuration has proven stable for my environment, I won't be testing further combinations of [...]-offload controller flag disablement.
Having said that, it's worth noting that not observing a hardware hangup does not necessarily equate to having a bullet-proof controller configuration. In a different environment, the other offloading features might still cause trouble. However, they haven't posed an issue in my specific environment, since they might have not have been brought into operation. One such feature is VLAN acceleration ([rx,tx]-vlan-offload). My network is in fact segmented into VLANs, but pve-03 is connected to an untagged port, hence it doesn't need to process 802.1Q frames. Someone might ask about VLANs on virtual interfaces. The answer is that none of the virtual interfaces on that hypervisor use VLANs either.
Persisting the working configuration
The relevant offloading features need to be disabled every time the interface is enabled. On Debian-based systems (e.g. PVE), this can be achieved using the post-up directive in /etc/network/interfaces:
auto lo
iface lo inet loopback
iface eno1 inet manual
> post-up ethtool --features eno1 tso off
auto vmbr0
iface vmbr0 inet dhcp
bridge-ports eno1
bridge-stp off
bridge-fd 0
That's all for today 👩💻. I hope you found this helpful!
